Kimpok 3.3GHz 16 Channel High Sensitivity Analog Video Receiver VRX for Long-Range Wireless Video Transmission

Kimpok 3.3GHz 16CH High Sensitivity Analog Video Receiver VRX for Long-Range Wireless Video Transmission

Product Description

The KP-R3300-B is a high-sensitivity 3.3GHz analog video receiver designed for stable long-range wireless video reception in complex environments. Operating in a lower-frequency band than common 5.8GHz systems, it offers improved signal penetration, reduced attenuation, and stronger resistance to interference.

With 16 selectable channels and wide input voltage support, this receiver delivers reliable analog video performance for demanding wireless image transmission applications.

Key Features

• Enhanced Signal Penetration
  The 3.3GHz band provides stronger penetration through foliage, light structures, and other non-metallic obstacles, maintaining a more stable video signal in challenging environments.

• Extended Reception Range
  Lower signal attenuation helps achieve longer reception distances in open, unobstructed conditions.

• Reduced RF Interference
  The 3.3GHz spectrum is less crowded than 5.8GHz, minimizing interference from common wireless devices and improving overall link stability.

• High Sensitivity Reception
  With reception sensitivity up to -97dBm, the receiver captures weaker signals for clearer long-distance video.

• Wide Voltage Compatibility
  Supports 7–36V DC input, compatible with various power supply systems.

• Auxiliary Power Output
  Provides 5V/0.5A output for powering external devices such as displays or signal processors.

Advantages

✔ More stable video reception in obstructed environments
✔ Longer usable range compared to higher-frequency systems
✔ Cleaner video with less background RF noise
✔ High sensitivity for improved weak-signal performance
✔ Flexible integration with different power systems

Applications

• Long-range wireless video reception systems

• Ground-based monitoring stations

• Industrial inspection and observation platforms

• Mobile video reception setups

• RF testing and experimental projects

Specifications

3.3GHz Analog Video Receiver

16 Channel VRX

High Sensitivity Wireless Video Receiver
